4 Hooks Airdrop Payload Release Mechanism System for DJI M300 The 4-hooks airdrop payload release mechanism system for the DJI M300 is engineered for precision payload delivery operations. Utilizing DJI OSDK technology, this system enables seamless drop and release control directly through the DJI ...
Brand Name:AOISUN
Minimum Order Quantity:1
Product Custom Attributes
Highlight
4 Hooks DJI Drop System
,DJI Drop System 10W
,Drone Delivery Mechanism IP4X
Name:
DJI Drop System
Installation Port:
T-Port
Size:
57.4 X 57.4 X 49 Mm
Weight:
99g
Degree Protection:
IP4X
Supported Models:
Matrice 300 RTK、Matrice 200 V2
Most Power:
10W
Hook:
4
Mounting Weight Per Hook:
5kg
Total Weight:
20kg
Delivery Function:
Unlimited Order
Product Description
4 Hooks Airdrop Payload Release Mechanism System for DJI M300
The 4-hooks airdrop payload release mechanism system for the DJI M300 is engineered for precision payload delivery operations. Utilizing DJI OSDK technology, this system enables seamless drop and release control directly through the DJI Pilot remote controller.
System Overview
This advanced release mechanism integrates four independent airdrop hooks with unlimited sequencing capability. The carbon fiber and aluminum alloy construction ensures exceptional strength and durability while maintaining lightweight performance. Each hook supports a maximum payload capacity of 5kg, with a total system capacity of 20kg.
Key Features
- DJI Pilot Integration: Complete operational control through the DJI Pilot remote controller interface
- Quick-Release Bracket: T-port mounting system for easy installation with plug-and-play functionality
- Smart Hook Recognition: Four mounting positions with automatic position identification and real-time status display
- Flexible Release Control: Independent hook operation with unlimited release sequencing and one-click deployment
- Robust Construction: Carbon fiber and aluminum alloy materials for optimal strength-to-weight ratio
Technical Specifications
| Product | M300 Drop Release Kits |
|---|---|
| Installation Port | T-Port |
| Dimensions | 57.4 x 57.4 x 49 mm |
| Weight | 99g |
| IP Protection Rating | IP4X |
| Supported Models | Matrice 300 RTK, Matrice 200 V2 |
| Maximum Power | 10W |
| Number of Hooks | 4 |
| Payload per Hook | 5kg |
| Total System Capacity | 20kg |
| Delivery Function | Unlimited Order Sequencing |
| Mounting Operation | Point and One-Key Release |
| Installation Mode | Quick-Release Type |
| Operating Temperature | -10℃ to 50℃ |
