Lightweight DJI Matrice 400 Payload Tethered Drone Power Station Portable

Tired of drone hover time constraints disrupting your long-duration missions? The DJI M400 RTK Drone, when paired with its dedicated tethered power station, delivers a definitive solution—enabling stable continuous hovering for up to 48 hours. Eliminate the need for frequent landing and recharging: this integrated system maintains reliable airborne operation, making it the ideal choice for round-the-clock surveillance, high-altitude mapping, and non-stop monitoring tasks. Minimize operational downtime, ensure seamless workflows, and stay focused on your core objectives.

• Flight Altitude Support: ≥ 100 meters (equipped with an 110-meter professional-grade tethered cable, including 10 meters of redundant length for enhanced safety and operational flexibility).
• Continuous Flight Duration: ≥ 24 hours (note: actual endurance may vary based on the drone’s structural integrity and electrical system durability).
• Optional Lighting Upgrade: 800W high-power lighting module (available as an add-on for low-light or nighttime operations).

1.  Lightweight, Portable & Rapid Deployment

   Boasting a compact, lightweight design, the system can be easily carried by a single person. It supports quick on-site deployment, perfectly meeting the demands of mobile missions and time-sensitive operations.

2. Multi-Layer Protection for Safe, Reliable Operation
   • Electrical Isolation: Complete separation of AC high voltage and DC low voltage ensures operational safety.
   • Comprehensive Protection Mechanisms: Equipped with input overvoltage/undervoltage protection, output overcurrent/short-circuit protection, and automatic fault detection & recovery—guaranteeing stable system performance.
   • Ultra-High Voltage Withstand: Rated for ≥ 3000VDC, ensuring durability in harsh electrical environments.
3.  Low-Voltage Start (No AC Air Switch Required) – Enhanced Safety

   Adopting a low-voltage soft-start mode (replacing traditional circuit breaker activation), the system features an ultra-high waterproof rating that far exceeds standard air switches—further improving safety during isolated AC contact use.

4. 4.3-Inch Touchscreen Display
   • Real-Time Monitoring: Displays key electrical parameters (real-time power, voltage, current, temperature, cable length, power consumption, running time) at a glance.
   • Data Visualization: Includes voltage/current/temperature curves, fault records, and log storage/retrieval for comprehensive operational tracking.
5. Stable Power Supply & Extended Battery Lifespan

   The onboard module delivers constant-voltage output, eliminating inefficient charging/discharging losses, protecting the drone’s battery lifespan, and maintaining a fully charged standby state throughout operations.

6.  Intelligent Winch with Automated Control

   Automatically retracts and deploys the tethered cable in sync with the drone’s takeoff and landing. The fully automated process eliminates the need for manual cable operation, reducing operational complexity and boosting task efficiency.

7.  Uninterrupted Power & Intelligent Cable Retraction
   • Built-in backup power supply: In the event of a sudden power outage, the system automatically switches to backup power mode to complete emergency cable retraction—avoiding cable entanglement risks.

8. Intelligent Communication Management System

   • Wired Communication (GCS ↔ Ground Power Module): USB Type-C or RJ45 for high-speed data transmission.
   • Wireless Communication (GCS ↔ Ground Power Module): Bluetooth 5.0 low-power connection for flexible operation.
   • Fiber Optic Communication (GCS ↔ Drone): Enables ultra-fast, stable data transmission for critical mission data.
