YWG-40 Airborne Firefighting Hose Assembly with Quick-Detach Installation, Adjustable Jet Angle and 40mm Diameter Hose
| MOQ: | 1 |
| Standard Packaging: | case |
| Delivery Period: | 2 weeks |
| Payment Method: | L/C,D/A,D/P,T/T |
Detail Information
Brand Name
AOISUN
Model Number
YWG-40
Name:
Airborne Firefighting Hose Assembly Model YWG-40
Size:
2480×55×140mm
Hose:
40mm Diameter, 90m Length
Gun Size:
2500mm/1.1kg
Spray Tube:
20mm
Nstallation & Operation:
Quick-detach Mounting, Manually Adjustable Jet Angle
Performance Indicators:
Operating Height 0~70m, Effective Jet Range 10~15m; Rated Pressure 2.5Mpa, Burst Pressure 3.2Mpa
Extinguishing Agent Compatibility:
Compatible With Fire-fighting Foam And Aqueous Agent
Highlight:
Adjustable DJI Flycart Payload
,DJI Flycart Payload 20kw
,30kw Tethered Drone Solutions
Product Description
Airborne Firefighting Hose Assembly (Model YWG-40) with Quick-Detach Installation & Adjustable Jet Angle
Product Overview
The YWG-40 airborne firefighting hose assembly is a high-performance fire suppression solution designed for airborne platforms. This system integrates portability, flexibility, and reliability to meet the demanding requirements of emergency fire-fighting operations across diverse scenarios.
Technical Specifications
| Specification | Value |
|---|---|
| Overall Dimensions | 2480 * 55 * 140mm |
| Spray Gun Length | 2500mm |
| Spray Gun Weight | 1.1kg |
| Spray Tube Caliber | 20mm |
| Fire Hose Diameter | 40mm |
| Fire Hose Length | 90m |
Key Features
- Quick-detach installation design for rapid mounting and dismounting on airborne platforms
- Manually adjustable jet angle for precise targeting of fire sources at different positions
- Integral forged joint for hose connection enhances sealing, durability, and prevents leakage/detachment
Extinguishing Agent Compatibility
Supports two types of fire-fighting media: fire-fighting foam and fire-fighting aqueous agent. This adaptability makes the system suitable for various fire types including solid combustible fires and liquid fuel fires.
Performance Specifications
- Recommended operating height: 0m to 70m
- Effective spray range: 10m to 15m for wide fire coverage
Pressure Resistance
Rated pressure resistance: 2.5Mpa
Burst pressure: 3.2Mpa
Ensures structural stability and reliability under high-pressure conditions.
